- ■Adopts a cross blade for cutting edge that enables penetration through deck plates.
- ■Hole drilling at nearly perfect circles enabled. This realizes smooth anchor insertion.
- ■Cross blade less likely to become trapped with less wear of the cutting edge and outside diameter, when hitting against reinforcement bars. Stable drilling ability is maintained.
◆Matching drill: Rotary hammer drill
A wide range of sizes to meet the broad needs of the work environment. Demonstrate an outstanding cutting feel with uniquely designed cutting edge shape and angle employing ultra-hard tips with emphasis on durability. Soegijapranata Catholic University is a leading higher education institution with an institutional accreditation of A in Semarang, Central Java, Indonesia.
(700KB)
■Product promotion video
![Drivers Drivers](https://www.unika.co.jp/en/products/concrete/images/cd9_rj.jpg)
Uses
Deck plate + Concrete•Block•
Brick•Mortar•Japanese wall•Stone
■Cross blade penetrates through deck plate
The cross blade developed to enable penetration through deck plate reduces the cross angle and prevents a reduction in drilling speed with the 2-edge (main, auxiliary) construction.
Realizes hole drilling at nearly a perfect circle by proactively operating the auxiliary edge to outer circumference cutting.
■Hole drilling at nearly perfect circles realized
Drivers Unika Jobs
![Unika Unika](https://monet.asia/wp-content/uploads/product/trusco/img/DP5RJ34_8018-300x300.jpg)
Adopts the cross blade for cutting edge that enables not only penetration through deck plates but also hole drilling close to a perfect circle. In addition, anchor insertion is smoothly performed and the vibration burden during work is reduced.
■Installation Example (Unicon Anchor)
![Drivers Drivers](https://www.bedroomsplusonline.co.uk/images/unika-colorfill-worktop-joint-sealer-cf437-grey-oak-p616-3459_image.jpg)
- Drill a hole above the deck plate at a specified hole diameter and to a specified hole depth.
- Remove shavings with a dust collector or blower.
- Strike a cone with a striking rod to set the anchor.
- Screw a full thread bolt, etc. This completes installation.
<Dia>
3.2?6.4mm
Overall length
110mm
(30*10*158)<Dia>
3.4?5.5mm
Overall length
160mm
(30*10*212)<Dia>
6.0-18.0mm
(37*13*214)
*( ) The number inside is package size. W*D*H(mm). As for size there is the error of ±2mm depending upon the package.
- Use the SDS chucking type electrical drills.
- Use the drill in the 'Hammering-in' mode only.
- Be sure to turn off the main switch of the electrical drill and disconnect the power supply plug from the socket before attaching and detaching the drill bit.
- Push in the drill bit until the locked position.
- Wear eye protection glasses.
- Drill holes vertically against the drilled material surface.
- Read the instruction manual for the electrical drill used carefully before use and always observe those instructions to ensure safe and correct operation.
Drivers Unika Edu
Size | Dia(mm) | Overall Length(mm) | Effective Length(mm) | Pcs./box | JAN Code |
---|---|---|---|---|---|
UX6.0X160 | 6.0 | 160 | 100 | 10 | 4989270111783 |
UX6.4X160 | 6.4 | 4989270111790 | |||
UX6.5X160 | 6.5 | 4989270111806 | |||
UX7.0X160 | 7.0 | 4989270111813 | |||
UX7.2X160 | 7.2 | 4989270111820 | |||
UX7.5X160 | 7.5 | 4989270111837 | |||
UX8.0X160 | 8.0 | 4989270111417 | |||
UX8.5X160 | 8.5 | 4989270111424 | |||
UX9.0X160 | 9.0 | 4989270111431 | |||
UX9.5X160 | 9.5 | 4989270111448 | |||
UX10.0X160 | 10.0 | 4989270111455 | |||
UX10.5X160 | 10.5 | 4989270111462 | |||
UX11.0X160 | 11.0 | 4989270111479 | |||
UX12.0X160 | 12.0 | 4989270111493 | |||
UX12.5X160 | 12.5 | 4989270111509 | |||
UX12.7X160 | 12.7 | 4989270111516 | |||
UX13.0X160 | 13.0 | 4989270111523 | |||
UX13.5X160 | 13.5 | 4989270111530 | |||
UX14.0X160 | 14.0 | 4989270111547 | |||
UX14.3X160 | 14.3 | 4989270111554 | |||
UX14.5X160 | 14.5 | 4989270111561 | |||
UX15.0X160 | 15.0 | 160 | 100 | 6 | 4989270111592 |
UX16.0X160 | 16.0 | 4989270111585 | |||
UX16.5X160 | 16.5 | 4989270111578 | |||
UX17.0X160 | 17.0 | 4989270111608 | |||
UX18.0X160 | 18.0 | 4989270111615 |
(Price revised as of May 1, 2009.)
Size | Dia(mm) | Overall Length(mm) | Effective Length(mm) | Pcs./box | JAN Code |
---|---|---|---|---|---|
UXL8.0X210 | 8.0 | 210 | 150 | 1 | 4989270102019 |
UXL8.5X210 | 8.5 | 4989270102026 | |||
UXL9.0X210 | 9.0 | 4989270102033 | |||
UXL10.0X210 | 10.0 | 4989270102040 | |||
UXL10.5X210 | 10.5 | 4989270102057 | |||
UXL12.0X210 | 12.0 | 4989270102064 | |||
UXL12.5X210 | 12.5 | 4989270102071 | |||
UXL12.7X210 | 12.7 | 4989270102088 | |||
UXL14.0X210 | 14.0 | 4989270111622 | |||
UXL14.5X210 | 14.5 | 4989270102095 | |||
UXL15.0X210 | 15.0 | 4989270102101 | |||
UXL16.0X210 | 16.0 | 4989270102118 | |||
UXL17.0X210 | 17.0 | 4989270102125 | |||
UXL18.0X210 | 18.0 | 4989270111639 | |||
UXL19.0X210 | 19.0 | 4989270102132 | |||
UXL20.0X210 | 20.0 | 4989270102149 | |||
UXL10.0X260 | 10.0 | 260 | 200 | 1 | 4989270102156 |
UXL10.5X260 | 10.5 | 4989270102163 | |||
UXL12.0X260 | 12.0 | 4989270102170 | |||
UXL12.5X260 | 12.5 | 4989270102187 | |||
UXL12.7X260 | 12.7 | 4989270102194 | |||
UXL14.0X260 | 14.0 | 4989270102200 | |||
UXL14.5X260 | 14.5 | 4989270111646 | |||
UXL15.0X260 | 15.0 | 4989270111653 | |||
UXL16.0X260 | 16.0 | 4989270111660 | |||
UXL16.5X260 | 16.5 | 4989270111677 | |||
UXL17.0X260 | 17.0 | 4989270111684 | |||
UXL18.0X260 | 18.0 | 4989270111691 | |||
UXL19.0X260 | 19.0 | 4989270111714 | |||
UXL20.0X260 | 20.0 | 4989270111721 | |||
UXL22.0X260 | 22.0 | 4989270111851 | |||
UXL23.0X260 | 23.0 | 4989270102217 | |||
UXL24.0X260 | 24.0 | 4989270111868 | |||
UXL25.0X260 | 25.0 | 4989270111875 | |||
UXL26.0X260 | 26.0 | 4989270102224 | |||
UXL10.0X350 | 10.0 | 350 | 290 | 1 | 4989270102231 |
UXL10.5X350 | 10.5 | 4989270102248 | |||
UXL11.0X350 | 11.0 | 4989270102255 | |||
UXL12.0X350 | 12.0 | 4989270102262 | |||
UXL12.5X350 | 12.5 | 4989270102279 | |||
UXL12.7X350 | 12.7 | 4989270102286 | |||
UXL13.0X350 | 13.0 | 4989270102293 | |||
UXL14.0X350 | 14.0 | 4989270102309 | |||
UXL14.3X350 | 14.3 | 4989270102316 | |||
UXL14.5X350 | 14.5 | 4989270102323 | |||
UXL15.0X350 | 15.0 | 4989270102330 | |||
UXL16.0X350 | 16.0 | 4989270102347 | |||
UXL16.5X350 | 16.5 | 4989270111738 | |||
UXL17.0X350 | 17.0 | 4989270111745 | |||
UXL17.5X350 | 17.5 | 4989270102354 | |||
UXL18.0X350 | 18.0 | 4989270111752 | |||
UXL19.0X350 | 19.0 | 4989270111769 | |||
UXL20.0X350 | 20.0 | 4989270111776 | |||
UXL22.0X350 | 22.0 | 4989270102361 | |||
UXL23.0X350 | 23.0 | 4989270102378 | |||
UXL24.0X350 | 24.0 | 4989270102385 | |||
UXL25.0X350 | 25.0 | 4989270102392 | |||
UXL26.0X350 | 26.0 | 4989270102408 | |||
UXL10.0X450 | 10.0 | 450 | 390 | 1 | 4989270102415 |
UXL10.5X450 | 10.5 | 4989270102422 | |||
UXL12.0X450 | 12.0 | 4989270102439 | |||
UXL12.5X450 | 12.5 | 4989270102446 | |||
UXL13.5X450 | 13.5 | 4989270102453 | |||
UXL14.5X450 | 14.5 | 4989270102460 | |||
UXL16.0X450 | 16.0 | 4989270102477 | |||
UXL18.0X450 | 18.0 | 4989270102484 | |||
UXL19.0X450 | 19.0 | 4989270102491 | |||
UXL20.0X450 | 20.0 | 4989270102507 | |||
UXL22.0X450 | 22.0 | 4989270102514 | |||
UXL23.0X450 | 23.0 | 4989270102521 | |||
UXL24.0X450 | 24.0 | 4989270102538 | |||
UXL25.0X450 | 25.0 | 4989270102545 | |||
UXL26.0X450 | 26.0 | 4989270102552 |
(Price revised as of May 1, 2009.)
Size | Dia(mm) | Overall Length(mm) | Effective Length(mm) | Pcs./box | JAN Code |
---|---|---|---|---|---|
UXLL10.0X1000 | 10.0 | 1,000 | 200 | 1 | 4989270111899 |
UXLL12.0X1000 | 12.0 | 4989270111882 | |||
UXLL12.5X1000 | 12.5 | 4989270111707 |
TOOL BOX SET
The tool box set is also convenient for carrying and storing.
- (Overall length: 110mm type)3.5/4.3/4.8/5.0mm*each 1
- (Overall length: 160mm type)6.4/8.5/10.5/12.5/12.7/14.5mm*each 1
- JAN Code: 4989270102989
